A203 Pressure Vessel Steel Plate

PRODUCTS DESCRIPTION

ASTM A203 boiler container plates are available in five grades: Grade A, Grade B, Grade D, Grade E, and Grade F. ASTM A203 boiler container plates for grade A, B, D and E shall be normalized as required. The chemical composition shall conform to the requirements of ASTM A203/A203M. At the same time, ASTM A203 boiler container plate needs to do two mechanical properties test: namely tensile test and impact test. ASTM A203 boiler vessel plate is widely used in petroleum, chemical industry, power station, boiler and other industries, for the manufacture of reactor, heat exchanger, separator, spherical tank, oil and gas tank, high pressure pipeline, water turbine and other equipment and components.

Product Parameters

Product Name	A203 Pressure Vessel Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

A203	Upper limit of Chemical Element Content (%)
A203	C	Si	Mn	P	S	Ni
Class A	0.23	0.13-0.45	0.88	0.025	0.025	2.03-2.57
Class B	0.25	0.13-0.45	0.88	0.025	0.025	2.03-2.57
Class D	0.20	0.13-0.45	0.88	0.025	0.025	3.18-3.82
Class E	0.23	0.13-0.45	0.88	0.025	0.025	3.18-3.82
Class F	0.23	0.13-0.45	0.88	0.025	0.025	3.18-3.82

Mechanical Properties

A202	Tensile Strengthkis [MPa]	Yield Strength kis [MPa]	Elongation Gauge length 8in. [200mm], %	Elongation Gauge length 2in. [50mm], %
Grade A	65-85 [450-585]	37 [255]	19	23
Grade B	70-90 [485-620]	40 [275]	17	21
Grade D	65-85 [450-585]	37 [255]	19	23
Grade E	70-90 [485-620]	40 [275]	17	21
Grade F	75-100 [515-690]	50 [345]	-	20

Physical Performance

Physical Performance	Metric	Imperial
Density	7.80 g/cc	0.282 lb/in³

Scope of Application

ASTM A203 boiler vessel plate is widely used in petroleum, chemical industry, power station, boiler and other industries, for the manufacture of reactor, heat exchanger, separator, spherical tank, oil and gas tank, high pressure pipeline, water turbine and other equipment and components.

FAQ

Q:What about your price?

A:Our price is very competitive because we are a factory. Pls feel free to contact us if you are interested in our products.

Q:What certifications do your products have?

A:We have ISO 9001, SGS, EWC and other certifications.

Q:What kind of payment terms would you accept?

A:We always do T/T.30% T/T as deposit,70% T/T as balance.

Q:What is your MOQ?

A:We will provide Original Mill Usually 25 tonnes, but it can be adjusted according to your needs and the actual situation of the inventory.

Q:What is the delivery time?

A:10-15 days

PACKING AND DELIVERY

PRODUCT TESTING

CLIENT FEEDBACK

Our factory products comply with CE/EN10204/ASTM/classification society certificates/CASO/BIS and other certificates, and all orders are subject to TPI (SGS/TUV/BV, etc.) inspection
