JIS G3101 SS400/SS490/SS540 Cold Rolled Steel Plate

SS400 is a marking method for Japanese steel materials and a judgment standard, which is equivalent to Q235 steel. Ordinary structural steel in Japanese steel (JIS series) grades mainly consists of three parts: SS400-S means steel, the second S means "structure", 400 is the lower limit tensile strength of 400MPa. SS400 steel plate itself not only has high strength, but also has certain comprehensive high-quality properties such as toughness, fatigue resistance, impact resistance, corrosion resistance, low temperature impact resistance, welding and easy processing. SS400 steel plates are widely used in construction and engineering structures.

Product Parameters

Product Name	JIS G3101 SS400/SS490/SS540 Cold Rolled Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film



Chemical Composition

Brand	Carbon	Manganese	Phosphorus	Sulphur
SS400	-	-	0.050 max	0.050 max
SS490	-	-	0.050 max	0.050 max
SS540	0.30 max	1.60 max	0.040 max	0.040 max



Mechanical Properties

Brand	Yield Strength				Tensile Strength
	≤ 16	16-40	40-100	> 100	-
SS400	245	235	215	205	400-510
SS490	285	275	255	245	490-610
SS540	400	390	-	-	540



Scope of Application

JIS G3101 scope of application: JIS G3101 steel plate and other steel grade products are suitable for general structural buildings, such as bridges and ships.

Q:What about your price?

A:Our price is very competitive because we are a factory. Pls feel free to contact us if you are interested in our products.

Q:What certifications do your products have?

A:We have ISO 9001, SGS, EWC and other certifications.

Q:What kind of payment terms would you accept?

A:We always do T/T.30% T/T as deposit,70% T/T as balance.

Q:What is your MOQ?

A:We will provide Original Mill Usually 25 tonnes, but it can be adjusted according to your needs and the actual situation of the inventory.

Q:What is the delivery time?

A:10-15 days

Our factory products comply with CE/EN10204/ASTM/classification society certificates/CASO/BIS and other certificates, and all orders are subject to TPI (SGS/TUV/BV, etc.) inspection
